High Temperature Stainless Steel Air Fittings , Quick Release Air Fittings
Why choose us
1: Various style for each products and completely series pneumatic products .
2: Large stock for fast shipping.
3: High quality with competitive price.
4: Sample order & small quantity order is acceptable.
5: Customize according to your special request.
6: Provide free products information.
7: Reliable quality assured and active after-sell service
8: One year quality guarantee
Product features
The materials ensure Anti-Corrosion highly,all of them are made from SUS316L except the seal ring
FKM is used as the seal ring,which can ensure Anti-Corrosion and acid resistant,also can be used in high temperature
The accessories are oil-free and reach the Food Hygiene Law of People's Republic of China,
which are applied widely in the range of industry such as food severice infustry,chemical industry and medical industry
Technical Specifications :
Materials :
Body : Stainless Steel 316L
Lock Claw/Release Button/C-lip : Stainless Steel 316L .
Collar : Stainless Steel 316L .
V-Seals : FKM/O-rings : FKM
Medium : Air , Water , Oil
Working pressure : 0~225PSI (0~15KG)
Vacuum rating : To 28”Hg
Working temperature : “-30℃ to 220℃
Applicable Tubings : PTFE, FEP, PU, PE, NYLON TUBES.PVDF...
Advantages :
* V-seals : We use V shape seals (FKM) instead of O-Ring , V-seale perfectly fit the
tube inserted and avoid any leaking !
* Tow O-rings design makes our Swivel function more Durable than One O-ring , Longer
life time !
FEATURES
. The materials ensure Anti - Corrosion highly , all of them are made from SU316L
except the seal ring .
. FKM is used as the seal ring , which can ensures Anti - Corrosion and acid
resistant , also can be used in high temperature .
. The accessories are oil - free and reach the Food Hygiene Law of People’s
Republic of China , which are applied widely in the range of industry such as food
service industry , chemical industry and medical industry .
Our products are high quality with 12 month guarantee ,and support paypal payment.
