PNV High Pressure Stainless Steel / Carbon Needle Valve Instruments Valve and Parts Inline Type Angle Type
Material Of Construction
| Description | Grade / ASTM Specification |
| Body Material |
| SS Carbon Steel |
| 1 | Handle | SS304 | A105 |
| 2 | Set Screw | SS304 | A105 |
| 3 | Lock Nut | SS304 | A105 |
| 4 | Packing Bolt | SS316 | A105 |
| 5 | Packing Gland | SS316 | A105 |
| 6 | Packing Washer | SS316 | SS304 |
| 7 | Packing | PTFE | PTFE |
| 8 | Bonnet | SS316 | A105 |
| 9 | Stem | SS316 | SS304 |
| 10 | Vee Tip | SS316 SS630 / A564 |
| Ball Tip |
| 11 | Stop Pin | SS304 | SS301 |
| 12 | Body | SS316 | A105 |
| 13 | Bleed | SS316 |
Model & External Dimension
Carbon / Stainless Steel High pressure Needle Valve
Thread M × F , F × F
Pressure : - 6000PSI ~ 10000 PSI
Why choose us
1: Various style for each products and completely series industry instruments.
2: Large stock for fast shipping .
3: High quality with competitive price .
4: Sample order & small quantity order is acceptable .
5: Customize according to your special request .
FAQ
Q: Could you offer the free samples ?
A: Yeah, we could offer the free samples based on special customer.pre-production sample,production sample.
Q: What ' s your business scope ?
A: High qulaity industry instruments is our business scope .Include Flow meter,Water meter,Manometer,Pressure ,Temperature,Level transimitter and parts.and industry Valve for water,anticorrosion fluid.
Q: What is the price of the product ?
A: Our prices are based on the size and type of material , if you can give me the information ,
then we can give you an estimated price is for reference only . We can do any size and any desgin .
Q: What types of service ?
A: Supply technical information for your Working condition and give advise about details.
